Seamless Tube Oxygen Gas Cylinders
Our Seamless Tube Oxygen Gas Cylinders are developed from high quality seamless tube material. These are available in different working pressures, viz. 12mpa (120 BAR) and 15 mpa (150 BAR). Varying capacities are developed in these cylinders to exactly match your demand. The other specifications of our seamless tube oxygen gas cylinders, viz. weight, length and external diameter are subjected to change, if required we can also give 200Bar seamless tube oxygen gas cylinder available on 200 Bar working prassure on request.
SPECIFICATIONS TABLE
| Type |
Specification |
UP160 |
UP180 |
UP200 |
| Diameter |
mm |
506 |
506 |
506 |
| High |
mm |
1513 |
1613 |
1671 |
| Net Weight |
Kg |
125 |
135 |
145 |
| Max.Work.Pressure |
BAR(MPa) |
14(1.4) |
14(1.4) |
14(1.4) |
| Safety Valve Enactment Pressure |
BAR(MPa) |
16(1.6) |
16(1.6) |
16(1.6) |
| Static Evaporation Rate |
N2%/day |
2.2% |
2.0% |
1.9% |
| O2 Ar%/day |
1.5% |
1.4% |
1.2% |
| Geometry Volume |
L |
176 |
196 |
209 |
| Effective Volume |
L |
160 |
180 |
200 |
| Store Capacity (Nm3) |
N2 |
180 |
122 |
136 |
| O2 |
136 |
153 |
170 |
| Ar |
132 |
149 |
166 |
| Transporting Gas Capacity |
(Nm3/hr) |
10 |
10 |
11 |
| Material |
Stainless Steel |
Stainless Steel |
Stainless Steel |
| Surface Treatment |
Polishing |
Polishing |
Polishing |
| Bottom Seat |
Feet Circle |
Feet Circle |
Feet Circle |
| Liquid level Gauge |
Buoy |
Buoy |
Buoy |
Vacuum insulated cryogenic storage tanks have the following features:
- Stainless steel welded body and tank.
- Stabilizing pressure safety valves.
- Multiple layer insulation system.
- Used in storage and transport of liquefied air gas product(lo2,ln2,lar).
- Vacuum by advanced high diffusion pump.
- Advanced helium mass spectrum technique for checking vacuum.
- As inner tank of stainless steel so widely used in hospitals, pharmaceutical ind. , biology, chemicals, ships,foodstuff,energy, scientific labs etc.
Technical Specifications
| |
Working Pressure BAR(Mpa) |
Capacity (Liters) |
Outside Dia (mm) |
Length (mm) |
Weight Kg Aprox |
| 1 |
150 BAR (15 MPA) |
1.0 |
89 |
333 |
2.2 |
| 2 |
150 BAR (15 MPA) |
1.4 |
89 |
408 |
2.8 |
| 3 |
150 BAR (15 MPA) |
2.0 |
108 |
519 |
3.6 |
| 4 |
150 BAR (15 MPA) |
2.5 |
108 |
475 |
4.5 |
| 5 |
150 BAR (15 MPA) |
3.2 |
108 |
485 |
5.1 |
| 6 |
150 BAR (15 MPA) |
4.0 |
108 |
567 |
6.1 |
| 7 |
150 BAR (15 MPA) |
5.0 |
108 |
668 |
7.2 |
| 8 |
150 BAR (15 MPA) |
6.3 |
108 |
670 |
11.9 |
| 9 |
150 BAR (15 MPA) |
7.0 |
108 |
722 |
12.6 |
| 10 |
150 BAR (15 MPA) |
8.0 |
108 |
797 |
13.8 |
| 11 |
150 BAR (15 MPA) |
9.0 |
152 |
871 |
14.9 |
| 12 |
150 BAR (15 MPA) |
10.0 |
159 |
839 |
15.5 |
| 13 |
150 BAR (15 MPA) |
12.0 |
159 |
963 |
17.5 |
| 14 |
150 BAR (15 MPA) |
40.0 |
219 |
1445 |
56.3 |
| 15 |
125 BAR(12.5 MPA) |
40.0 |
|
1445 |
56.2 |
Note: The dimensions are indicative of the capacity.
